Reference design

A reference design allows developers to copy an IC design into a system/circuit without having to design everything from scratch. This saves time and resources. By copying the reference design, you also ensure that your IC will perform as expected.

You will find the reference designs in the Shop in the future, at the moment you can request them from us.

We help you to make the right component selection!

Shop
E-mail
Tel.: +49 89 546868-10

Our reference designs accelerate your product development

Reference designs are developed by GEYER Electronic for semiconductors from companies such as Texas Instruments, Analog Devices, MicroChip, Maxim Integrated, among others.

Our reference designs can be easily copied by you to save time. They usually contain all circuit information such as schematics, Gerber files, BOM – but also the design performances under different test conditions.

We create reference designs for your application

Our reference designs also help to make a quick and targeted component selection.

With us, you have access to established reference designs from well-known global IC manufacturers for many important application areas and technologies, such as

  • Wireless (Wireless MCU, LoRa, Zigbee, Sigfox, Bluetooth)
  • Networking: USB, LAN, HDSL
  • Controller
  • Data Conversion
  • DSP

and much more.
